Sightseeing Train Rides

Model No.: GS-TFT-72

The power source of trackless train is mainly divided into two kinds, fuel driven and battery driven. The main carriages are divided into two types: full enclosed compartments and open type carriages. As a special transportation tool, tourist train not only plays the role of transportation, but also makes visitors enjoy the scenery along the way. Some tourist trains can also provide leisure service.

PRODUCT INTRODUCTION
/static/themes/default/images/service_li.png
The power source of trackless train is mainly divided into two kinds, fuel driven and battery driven. The main carriages are divided into two types: full enclosed compartments and open type carriages.
As a special transportation tool, tourist train not only plays the role of transportation, but also makes visitors enjoy the scenery along the way. Some tourist trains can also provide leisure service.

 Diesel Tourist Train technical data
Performance
Capacity 72+2
Top speed 30km/h
Max. Climbing ability 25%,afford long time climbing
Min.Brake diatance 4m,under full load condition
Min.Turning Radius 7m
Dimensions
Overall dimension(m) 14.6*1.98*2.5
Locomotive and Carriage(mm) Locomotive: 4200*1700*2400    Carriage:4000*1980*2500
Wheelbase(mm) 2600
Tyre &Tread(mm) 14inch tyre ,tread 600-14
Min ground Clearance(mm) 145
Engine
Mode&brand QSB3.9-C80-3.1  Cummins diesel engine
Rated speed 2200
ECU brand BOSCH,Germany
Displacement  2.8T
Emission standard European standard IV
Gearbox  manual control 5+1
Brake system
Brake system type Air-assisted oil(Hydraulic drum air brake)
Emergency brakes   Brake automatically encounter the connectionbreak situation
Steering
Steering control Four-wheel steering
Drag system
Drag rod   Swing tow bar from China
Other configuration
Materials Body and seat:Fiberglass Chassis structure:Advanced steel pipe
Rust prevention Pickling + phosphating + rust paint
Painting automotive grade paint, computer paint, professional spray
Floor of carriages Stainless steel non-slip flooring
Lights  Front lights, combination taillights, warning lights, driving lights, brake lights, turn lights
Media players MP5 player, locomotive and carriages with the 7-inch display and 19-inch LED screen
Fan Movable mini fan
Camera system Brand-SAFUYWE,China 7 inch screen * 1, camera * 1, control center * 1. Each carriage has a built-in camera
Seat belt 3C certified seat belt
Plastic safety chains Chain*10pcs each carriage
Station reporter professional bus station reporting system with GPS
Smoke Blow smoke
Seat in locomotive The driver’s seat can be adjusted forwards and backwards

PRODUCT SUPERIORITY
/static/themes/default/images/service_li.png
1. Tourist Train is a special way of transportation in scenic area,at the same time, itself is an important tourist attraction.

/static/themes/default/images/service_li.png
2. Tourist Train can integrate multiple scenic spots, especially for large scenic spots, scenic small train is an effective tool to improve traffic accessibility of scenic spots.

/static/themes/default/images/service_li.png
3.To make Tourism landscape along the way to be rich and varied, various scenes, visual gluttonous dinner for tourists.

/static/themes/default/images/service_li.png
4.Sightseeing stations should be built along the Tourist Trains. Besides the necessary tourist facilities, scenic sightseeing stations should also have colorful tourist activities and projects.

/static/themes/default/images/service_li.png
5.Tourist Train can be effectively coordinated with other means of transportation, effectively organize the traffic system of scenic spots, and achieve seamless docking between scenic spots.
